304 s.s. impeller
304 s.s mechanical seal
Cast iron pump body and support be electrophoresis
Suction: 8M
Liquid: dean water,≤50°C
Liquid PH value: 6.5-8.5
Copper wire
With thermal protector
304 s.s shaft
Insulation class: B
IPX4
Ambient temperature: up to +40°C Liquid temperature: up to +40°C
Max Working pressure: 6 bar
It can be used to transfer clean water or other liquid similar to water in physical and chemical properties. It is suitable for lifting water from the well, sprinkling irrigation in garden, pressure boosting of running water; and supporting equipment etc.
| MODEL | POWER | MAX.FLOW (L/min) | MAX.HEAD (m) | MAX.SUCT (m) | INLET/OUTLET (n) | GW (kg) | PACKING DIMENSION (mm) | |
| kW | HP | |||||||
| JCP-30 | 0.45 | 0.6 | 40 | 35 | 9 | 1"×1” | 13 | 425×200×230 |
| JCP-40 | 0.6 | 0.8 | 45 | 40 | 9 | 1"×1" | 13.8 | 425×200×230 |
| JCP-50 | 0.75 | 1 | 50 | 45 | 9 | 1"×1" | 14.5 | 425×200×230 |
| JCP-60 | 1.1 | 1.5 | 60 | 55 | 9 | 1"×1" | 16 | 450×200×230 |
| JSW-45 | 0.45 | 0.6 | 40 | 35 | 9 | 1"×1” | 11 | 435×200×230 |
| JSW-55 | 0.75 | 1 | 55 | 45 | 9 | 1"×1" | 17.5 | 435×200×230 |
| JSW-65 | 1.1 | 1.5 | 70 | 55 | 9 | 1"×1" | 21.5 | 570×225×250 |
| JSW-75 | 1.5 | 2 | 70 | 65 | 9 | 11/4"×1" | 23.5 | 570×225×250 |
